ryanwhocodes Jul 27, 2018 · 5 min read

Docker ENTRYPOINT & CMD - Dockerfile Best Practices

How to use CMD and ENTRYPOINT effectively in your Dockerfiles for running containers.

The Docker instructions, CMD and ENTRYPOINT, are used in Dockerfiles and Docker Compose files to configure the commands used to run a container. This tutorial will explain the differences between them and how to best use them in your Dockerfiles.

Contents

Entrypoint

Entrypoint sets the command and parameters that will be executed first when a container is run.

Any command line arguments passed to docker run <image> will be appended to the entrypoint command, and will override all elements specified using CMD. For example, docker run <image> bash will add the command argument bash to the end of the entrypoint.

Dockerfile ENTRYPOINT

Dockerfiles use all uppercase letters for the entrypoint instruction. There are several ways you can define this.

The exec syntax

The exec form is where you specify commands and arguments as a JSON array. This means you need to use double quotes rather than single quotes.

ENTRYPOINT ["executable", "param1", "param2"]

Using this syntax, Docker will not use a command shell, which means that normal shell processing does not happen.If you need shell processing features, then you can start the JSON array with the shell command.

ENTRYPOINT [ "sh", "-c", "echo $HOME" ]

Using an entrypoint script

Another option is to use a script to run entrypoint commands for the container. By convention, it often includes entrypoint in the name. In this script, you can setup the app as well as load any configuration and environment variables. Here is an example of how you can run it in a Dockerfile with the ENTRYPOINT exec syntax.

COPY ./docker-entrypoint.sh /
ENTRYPOINT ["/docker-entrypoint.sh"]
CMD ["postgres"]

For example, the Postgres Official Image uses the following script as its ENTRYPOINT:

#!/bin/bash
set -e
if [ "$1" = 'postgres' ]; then
    chown -R postgres "$PGDATA"
    if [ -z "$(ls -A "$PGDATA")" ]; then
        gosu postgres initdb
    fi
    exec gosu postgres "$@"
fi
exec "$@"

Docker Compose entrypoint

The instruction that you use in your Docker Compose files is the same, except you use lowercase letters.

entrypoint: /code/entrypoint.sh

You can also define the entrypoint with lists in your docker-compose.yml.

  entrypoint:
    - php
    - -d
    - zend_extension=/usr/local/lib/php/xdebug.so
    - -d
    - memory_limit=-1
    - vendor/bin/phpunit

Overriding Entrypoint

You can override entrypoint instructions using the docker run --entrypoint or docker-compose run --entrypoint flags.

CMD / command

The main purpose of a CMD (Dockerfiles) / command (Docker Compose files) is to provide defaults when executing a container. These will be executed after the entrypoint.

For example, if you ran docker run <image>, then the commands and parameters specified by CMD / command in your Dockerfiles would be executed.

CMD in Dockerfiles

In Dockerfiles, you can define CMD defaults that include an executable. For example:

CMD ["executable","param1","param2"]

If they omit the executable, you must specify an ENTRYPOINT instruction as well.

CMD ["param1","param2"] # (as default parameters to ENTRYPOINT)

NOTE: There can only be one CMD instruction in a Dockerfile. If you list more than one CMD, then only the last CMD will take effect.

Docker Compose command

When using Docker Compose, you can define the same instruction in your docker-compose.yml, but it is written in lowercase as the full word command.

command: ["bundle", "exec", "thin", "-p", "3000"]

Overriding CMD

You can override the commands specified by CMD when you run a container.

    docker run rails_app rails console

If the user specifies arguments to docker run, then they will override the default specified in CMD.

Best practices

Although there are different ways to use these instructions, Docker gives some guidance on best practices for their use and syntax.

Usage best practices

Docker recommends using ENTRYPOINT to set the image’s main command, and then using CMD as the default flags. Here is an example Dockerfile that uses both instructions.

FROM ubuntu
ENTRYPOINT ["top", "-b"]
CMD ["-c"]

Syntax best practices

As well as the exec syntax, Docker allows shell syntax as another valid option for both ENTRYPOINT and CMD. This executes this command as a string and performs variable substitution.

  • ENTRYPOINT command param1 param2
  • CMD command param1 param2

However, this tutorial did not emphasise it due the exec syntax being seen as best practice.

CMD should almost always be used in the form of CMD [“executable”, “param1”, “param2”…]. Thus, if the image is for a service, such as Apache and Rails, you would run something like CMD ["apache2","-DFOREGROUND"]. Indeed, this form of the instruction is recommended for any service-based image.

The Dockerfile reference explains more about some of the issues.

The ENTRYPOINT shell form prevents any CMD or run command line arguments from being used, but has the disadvantage that your ENTRYPOINT will be started as a subcommand of /bin/sh -c, which does not pass signals. This means that the executable will not be the container’s PID 1 - and will not receive Unix signals - so your executable will not receive a SIGTERM from docker stop <container>

If CMD is used to provide default arguments for the ENTRYPOINT instruction, both the CMD and ENTRYPOINT instructions should be specified with the JSON array format.

Summary

Both CMD and ENTRYPOINT instructions define what command gets executed when running a container. There are few rules that describe how they interact.

  1. Dockerfiles should specify at least one of CMD or ENTRYPOINT commands.
  2. ENTRYPOINT should be defined when using the container as an executable.
  3. CMD should be used as a way of defining default arguments for an ENTRYPOINT command or for executing an ad-hoc command in a container.
  4. CMD will be overridden when running the container with alternative arguments.

Find out more

The Docker Documentation is a good place to learn more about Dockerfiles and see working examples of ways to use the commands.
